The recoil reduction of a muzzle brake with the comfort of a suppressor
NEXUS BY VANWARD & VISION
Nexus is designed and developed together with Vision & Design AS in Norway, with direct input from some of Norway’s most experienced PRS shooters. By combining Vision’s expertise in precision rifle shooting with Vanward’s experience in suppressor design and manufacturing, NEXUS brings together recoil control, sound suppression and shooter comfort in one compact system.
Recoil Suppression System
Nexus is a recoil suppression system, combining elite-level shooting experience with advanced suppressor engineering. Purpose built for precision rifle systems where recoil control, target observation, repeatability, and sound suppression are critical, while eliminating the excessive blast and shooter fatigue commonly associated with muzzle brakes.
Nexus is designed to help shooters stay on target through every shot. Its optimized recoil impulse, superior recoil reduction and integrated smoke redirection allow shooters to maintain their sight picture, observe impacts and deliver faster follow-up shots. The precision mounting system ensures secure, repeatable installation with consistent alignment and no zero shift between shooting sessions, while eliminating common suppressor issues such as gas leakage and carbon lock. Designed to deliver brake-level recoil control without the harsh blast and concussion of a traditional muzzle brake, Nexus provides a significantly more comfortable shooting experience without compromising performance. Its compact design offers exceptional recoil management and sound suppression in a lightweight package, making it equally suited for demanding hunting environments and competitive precision shooting.
- Purpose built for precision -
Ø48mm L150mm W257g 23-dB*
Cerakote finish
Features
-
Repeatable Zero
-
Fail-safe design
-
Up to 60% recoil reduction**
-
5-Year warranty
-
Magnum approved
Data
Diameter
Total length
Added length to the barrel
Max ø barrel
Weight
dB reduction
Calibers
Threads
48 mm
150 mm
150 mm
n/a
257 gr
23 dB*
.30
1/2x20, 1/2x28, 5/8x24, M13x1, M14x1, M14x1.5, M15x1, M18x1
Maintenance:
Vanward suppressor are generally maintenance free. Depending on use, it may require cleaning using suppressor cleaning solvents or ultrasonic cleaner.
Carbon build-up on Muzzle Brake & Front Brake is normal and should be removed as needed using a mild carbon remover and non-abrasive cleaning methods
*Measured 1.0 m left of muzzle, 1.6 m above ground, according to MIL-STD-1474D/E.
**Tested to 54% with 6.4kg rifle shooting 7.62x51 NATO ammo.
